AlfaNova

Manufactured with Alfa Laval’s patented AlfaFusion technology, AlfaNova is a heat exchanger consisting of corrugated stainless steel plates bonded together without any copper or nickel. The unique design means that AlfaNova can withstand more extreme temperatures and pressures with greater fatigue resistance than conventional brazed plate heat exchangers. It is also suitable for duties with very high hygiene demands.

More with AlfaNova

  • An optimal solution for hygienic applications such as tap water systems
  • Copper-free design is suitable for use with ammonia refrigerant and for clean water refrigeration chiller applications
  • Load distribution across many contact points secures excellent resistance to pressure fatigue
  • AHRI-certified for reliable thermal performance in a range of HVAC applications
  • Available with marine classification for use in a range of LPG/LNG duties, due to wide temperature range and copper-free construction

AlfaNova’s unique fusion-bonded manufacturing process provides greater reinforcement for the plate pack, which in turn ensures a higher degree of pressure resistance than that offered by comparable technologies. Additionally, the 100% stainless steel construction makes it possible to withstand temperatures as high as 550°C (1020°F). As a result, AlfaNova is highly dependable in applications with extreme pressure and/or temperature demands. Use of the same material for all key components also provides high thermal efficiency, in addition to giving the unit mechanical strength equivalent to any fully welded counterpart.

AHRI for HVAC

AlfaNova heat exchangers are available with certification according to the Liquid-to-Liquid Brazed and Fusion-Bonded Heat Exchanger programme of The Air-Conditioning, Heating, and Refrigeration Institute (AHRI). For heat exchangers used in HVAC applications, this programme offers independent, third-party verification of thermal performance according to manufacturers’ published specifications.

How it works

Two media at different temperatures flow on either side of thin corrugated stainless steel plates that are stacked on top of each other. The two media flow in a countercurrent flow through alternate channels and are held within the plate pack by a fusion-bonded seal around the edge of the plates. The points at which the plates are in contact with each other are also bonded with the same technology, reinforcing the pack against the pressure of the media inside.

The countercurrent flow makes it possible to extract heat efficiently even when there are only extremely small differences between the temperatures of the hot and cold media. This results in notable energy cost savings.

In some systems, co-current flows re also possible.

View the animation to learn more.


Edinstvene lastnosti za izboljšanje vaše učinkovitosti

Z več kot 80 leti inovacij na področju prenosa toplote pri Alfa Lavalu vemo, kaj je potrebno za doseganje visokozmogljivih rešitev za vsako uporabo. Naši strokovnjaki nenehno razvijajo nove inovacije, s katerimi naša serija toplotnih izmenjevalnikov AlfaNova postaja vedno zanesljivejša in učinkovitejša.

PressureSecure

Neprimerljiva moč za zahtevne naloge

Naše plošče z inovativno zasnovo podpirajo širok nabor aplikacij z visokimi temperaturami in visokim tlakom. Enote lahko delujejo s tanjšimi ploščami in manjšim številom plošč, kar pomeni manjšo porabo surovin in energije, manj hladilnega sredstva in daljšo življenjsko dobo opreme.



FlexFlow™

Vrhunska toplotna zmogljivost

Patentirana asimetrična zasnova plošč podjetja Alfa Laval je ena od mnogih edinstvenih novosti, ki vam omogoča izboljšan toplotni izkoristek s pomočjo optimiziranega padca tlaka in povečane turbulence. Poleg zmanjšanja porabe energije to pomeni zmanjšanje količine hladilnega sredstva in surovin.

AlfaNova®

100% nerjavno jeklo

AlfaNova® je rešitev, izdelana iz 100-odstotnega nerjavnega jekla, ki jo Alfa Laval omogoča na področjih, kjer se uporabljajo sredstva, ki niso skladna s klasičnimi materiali v toplotnih izmenjevalnikih. Ker je ta napredna zasnova optimizirana za uporabo z naravnimi hladilnimi sredstvi, jo je mogoče tudi popolnoma reciklirati.




Finding the right heat exchanger

With expertise from decades of experience in heat exchange, Alfa Laval offers guidance and useful tools to help you meet today’s heating and cooling challenges. Our product guide is an interactive resource you can use to find the ideal solution for your application.


.

Kontaktirajte nas

Imate vprašanje o portfelju lotanih in fuzijsko spojenih izmenjevalcev toplote? Mi vam pomagamo poiskati optimalno rešitev za vaše potrebe.
